InTANK




ST2760-S3 (1 floppy bay 2.5” JBOD)



Unique style



ST2760 is a internal JBOD module, which supports two 2.5” SATA hard drive, you can store the operating system and data file in different hard drive or use it with a RAID card. It is designed to has the same dimension as one 3.5” hard drive or one floppy size, this allows you to install ST2760 in the mini-Server, Surveillance Server, 1U Server, eMail Server and POS System that has limited space. ST2760 can help you to save the problem of requiring larger capacity but with limited space.

Compact dimension  Large capacity


ST2760 is the world first and smallest 2.5” SATA JBOD module.
Using the JBOD function enables you to store the operating system and data file in different hard disk space.The advantage of storage distribution can help to enhance the performance of system operation.
If you need a higher data backup function preservation, only through SATA Cable connection RAID Card or built-in support for RAID capabilities motherboard, you can upgrade your operating system with RAID function immediately into the work platform!



More iT2771-S3 product information  >>>>

ST2760-S3 Features

ST2760-S3 Product View

ST2760-S3 Specification



Model No ST2760-S3
Drive Bay 3.5" Floppy DriveBay
Drive Fit 2.5" SATA III HDD x 2 (9.5mm thickness)
RAID Level JBOD
Host Interface SATA III Connector (7Pin) x2
Power Supply SATA Connector (15Pin)
HDD Access Indicator LED
Color Matt Black
Structure Metal Body
Dimensions 101.7W x 147L x 25.8H(mm)
Weight 0.4(kg)
Certifications CE & FCC
Operating System
Support
Windows, Linux
Packing Content Accessory Kit
HDD Capacity Single HDD tested up to 2TB
Operating temperature 32° to 104° F (0° to 40° C)
Storage temperature -4° to 116° F (-20° to 47° C)
Relative humidity 5% to 95% noncondensing



Related Products



 iR2771

iT2776

iT2771









>>>> More External RAID Storage

ST2760-S3 Download

Product
Datasheet
QM
UM
CE & FCC
other
ST2760-S3

ST2760-S3 Question & Answer
